Pneumatic Jet Fan, 24 in dia Inner, 4 Blades, 16000 ft³/min, 76 to 338 SCFM, 40 to 100 psig

037-9518-24

Product Description

Heavy-duty aluminum fan can be used as a blower or exhaust by simply reverse mounting. Compressed air is pushed through a nozzle at the end of each blade creating the fan to propel at speeds up to 10,500 CFM (20-inch model) or 16,000 CFM (24-inch model) at 100 psig quickly and efficiently. Heavy-duty ball bearings are permanently lubricated and sealed for the life of the fan. A spark-resistant fan with recessed handles for easy portability or it can be rolled.

Specifications

Air Consumption [Max] 338 SCFM
Air Consumption [Min] 76 SCFM
Blade Material Heavy-Duty Aluminum
Color Gray
Dia. [Max] 32.75 in
Dia. [Min] 24 in
Fan Type Blower; Exhaust
Height [Nom] 11.75 in
Inlet Pressure [Max] 100 psig
Inlet Pressure [Min] 40 psig
Inlet Size 1 in
Inlet Type NPT
Material Aluminum; Stainless Steel Fan Shaft
Mounting Side-Mounted Inlet Connector
No. of Blades 4
Power Source Pneumatic
Speed [Max] 16000 ft³/min
